Agricultural Steel Wheel Rim Trailer Wheel (9.00X15.3 13.00X15.5 16.00X17 16.00X22.5 20.00X22.5 20.00X26.5 20.00X30.5 24.00X26.5 24.00X30.5 28.00X30.5)
Agricultural Steel Wheel Rim Trailer Wheel (9.00X15.3 13.00X15.5 16.00X17 16.00X22.5 20.00X22.5 20.00X26.5 20.00X30.5 24.00X26.5 24.00X30.5 28.00X30.5)Product detail:1. Steel wheels within diameters from 12" up to 54", and width from 4.25" up to 36"2. Wheels for speeds up to 65km......
Send Inquiry
Product Description
Agricultural Steel Wheel Rim Trailer Wheel (9.00X15.3 13.00X15.5 16.00X17 16.00X22.5 20.00X22.5 20.00X26.5 20.00X30.5 24.00X26.5 24.00X30.5 28.00X30.5)
Product detail:
1. Steel wheels within diameters from 12" up to 54", and width from 4.25" up to 36"
2. Wheels for speeds up to 65km/h
3. The high quality of manufactured wheel is comply to TRA, TROTA standard
4. Wheel rims for tractors, trailers, harvesters etc applications
Wheel sizes
| Dia | Wheel Size | Tire Size | Dia | Wheel Size | Tire Size |
| 12'' | 5J*12 | 7.00*12 6.00-12 | 26" | W12*26 | 13.6-26 14.9-26 |
| 7.00*12 | 10.0/75-12 10.0/8-12 23/8.50*12 | W13*26 | 14.9-26 | ||
| 8.50*12 | 11.0/65-12 23/9.50*12 | W15*26 | 16.9-26 | ||
| 10.50*12 | 26*12.0-12 | W16*26 | 18.4-26 | ||
| 13'' | 4J*13 | 5.50-13 165RS13 | DW20*26 | 23.1-26 24L-26 | |
| 4.5J*13 | 5.50-13 | DW25*26 | 30.5L-26 28L-26 | ||
| 14'' | 4.5J*14 | 6.5-14 | 26.5" | 16.00*26.5 | 500/60-26.5 |
| 6.00*14 | 9.5L*14 | 20.00*26.5 | 600/55-26.5 | ||
| 7.00*14 | 9.5L*14 | 24.00*26.5 | 700/50-26.5 | ||
| 15" | 4J*15 | 5.00-15 | 28.00*26.5 | 800/45-26.5 | |
| 5J*15 | 6.5/80-15 | 28" | W8*28 | 9.50-28 | |
| 6LB*15 | 7.5L-15 | W10*28 | 11.2-28 | ||
| 7J*15 | 8.0/75-15 | W11*28 | 12.4-28 | ||
| 8LB*15 | 27*10.5-15 11L-15 | W12*28 | 13.6-28 | ||
| 9LB*15 | 11L-15 | W13*28 | 14.9-28 | ||
| 10LB*15 | 12.5L-15 29*12.5-5 31*15.5-15 | W14L*28 | 16.9-28 | ||
| 13LB*15 | 33*15.5-15 31*15.5-15 | DW15L*28 | 16.9-28 | ||
| 15.3" | 15.3*9.00 | 10.0/75-15.3 11.5/80-15.3 12.5/80-5.3 | W16*28 | 18.4-28 | |
| 15.5" | 15.5*13.00 | 400/60-15.5 | DW18*28 | 21L-28 | |
| 16" | 4.5E*16 | 6.00-16,6.50-16 | DW20*28 | 600/50-28 | |
| 5.50E*16 | 7.50-16 | 30" | W12*30 | 13.6-30 | |
| 6.50*16 | 8.25-16 | W14L*30 | 16.6-30 | ||
| W7*16 | 210/85R16 | DW14*30 | 16.9-30 | ||
| W8*16 | 10.0/75-16 19.0/65-16 10.00-16 | W15L*30 | 18.4-30 | ||
| W9*16 | 285/70R16 11.00-16 | DW16L*30 | 18.4-30 23.1*30 | ||
| 9.00*16 | 11L-16 | DW20*30 | 23.1*30 | ||
| 11.00*16 | 14.0/65-16 | 30.5" | 20.00*30.5 | 600/50-30.5 800/60-30.5 | |
| 16.1" | 11.0*16.1 | 14L-16.1 | 24.00*30.5 | 650/80-30.5 700/50-30.5 750/60-30.5 | |
| 14.00*16.1 | 16.5-16.1 | 28.00*30.5 | 800/45-30.5 800/55-30.5 | ||
| 850/50-30.5 | |||||
| 16.00*16.1 | 21.5-16.1 | 32" | W7*32 | 8.30-32 | |
| 16.5" | 8.25*16.5 | 10-16.5 | W10*32 | 12.4-32 | |
| 9.75*16.5 | 12-16.5 | W12*32 | 13.6-32 | ||
| 12.00*16.5 | 33/15.5-16.5 | DW20*32 | 23.1-32 | ||
| 17" | 17*13.00 | 15.0/55-17 | DW21*32 | 24.5R32 680/70R32 680/75R32 | |
| 17*16.00 | 19.0/45-17 500/50-17 | DW27*32 | 30.5L-32 800/65R32 | ||
| 17.5" | 10.75*17.5 | 14-17.5 | 34" | DW10*34 | 12.4-34 |
| 11.75*17.5 | 14-17.5 | W14L*34 | 16.9-34 | ||
| 18" | 9.00*18 | 10.5/80-18 12.5/80-18 | W15L*34 | 18.4-34 | |
| W9*18 | 10.5/80-18 12.5/80-18 | DW15*34 | 16.9-34 | ||
| 11.00*18 | 13.00/65-18 | DW16*34 | 18.4-34 | ||
| 13.00*18 | 15.0/70-18 15.5/60-18 405/70-18 | DW20*34 | 23.1-34 | ||
| 19" | 3.00*19 | 4.50*19 | 36" | W8*36 | 9.50-36 |
| 19.5" | 14*19.5 | 15.0*19.5 | W10*36 | 11.2-36 | |
| 20" | 5.50*20 | 7.50*20 | W11*36 | 14.9-36 | |
| W7*20 | 8.3-20 | W12*36 | 14.9-36 | ||
| W8*20 | 9.50-20 | 38" | W10*38 | 11.5*38 | |
| 20*8.00 | 9.5-20 10.00-20 | W11*38 | 13.6-38 14.9-38 | ||
| W9*20 | 11.2-20 | W12*38 | 13.6-38 14.9-38 | ||
| 10.00*20 | 12.00-20 | W15L*38 | 16.9-38 540/65*38 | ||
| W11*20 | 12.4*20 | W16*38 | 18.4-38 | ||
| 13.00*20.00 | 405/70-20 425/65R20 425/75R20 | DW16*38 | 18.4-38 | ||
| 14.00*20.00 | 38/18-20 | DW20*38 | 650/65-38 | ||
| 20.5" | 14*20.5 | 465/65R20.5 | DW23*38 | 710/70R38 | |
| 21" | 18.00*21 3pcs | 24R21 | W8*42 | 8.30-42 | |
| 22.5" | 11.75*22.5 | 15R22.5 365/70R22.5 385/65R2.5 | 42" | W10*42 | 11.2-42 |
| 13.00*22.5 | 16.5R22.5 425/65-22.5 415/45R22.5 | DW16*42 | 18.4-42 | ||
| 14.00*22.5 | 18R22.5 465/65R22.5 | DW18*42 | 20.8-42 | ||
| 16.00*22.5 | 500/60-22.5 550/60-22.5 550/45-22.5 | W20*42 | 620/70*42 | ||
| 20.00*22.5 | 600/50-22.5 650/50-22.5 600/55-22.5 | DW23*42 | 710/70*42 | ||
| 24.00*22.5 | 700/50-22.5 | DW27*42 | 900/60*42 | ||
| 24" | W7*24 | 8.3-24 | 44" | W8*44 | 10.00*44 |
| W8*24 | 9.50-24 | W10*44 | 12.4*44 | ||
| W10*24 | 11.2-24 | 46" | DW10*46 | 11.2-46 | |
| W12*24 | 13.6-24 14.9-24 | DW12*46 | 12.4-46 | ||
| W14L*24 | 16.9-24 | DW13*46 | 14.9-46 | ||
| DW15L*24 | 16.9-24 | DW16*46 | 18.4-46 520/85-46 | ||
| DW16L*24 | 19.5L-24 18.4-24 | 48" | W8*48 | 9.50-48 | |
| DW18L*24 | 20.5-24 | W10*48 | 11.2-48 | ||
| 24.5" | 24.5*8.25 | 11R24.5 | W12*48 | 16.3-48 | |
| 24.5*11.75 | 385/55R24.5 | 50" | W10*50 | 12.4-50 | |
| 24.5*13.00 | 16.5R24.5 425/65R24.5 | W16*50 | 18.4-50 | ||
| 25" | 36.00*25 | 66/43-25 | 52" | W10*52 | 12.4-52 |
